Intel Core i7-1260P, 12C (4P + 8E)/16T, P-core 2.1/4.7GHz, E-core 1.5/3.4GHz, 18MB, 16GB DDR4-3200 non-ECC, 512GB SSD M.2 2280 PCIe x4 Value NVMe Opal2, 16" FHD+ (1920x1200) IPS 300nits Anti-glare 45% NTSC, NVIDIA Quadro T550 4GB, Intel AX211 Wi-Fi 6E 2x2 + BT5.1, IR & FHD 1080p with Privacy Shutter, Windows 11 DG Windows 10 Pro 64
Real power meets real freedom
- Powerful, high-performance 16" mobile workstation, ISV-certified
- Latest Intel® Core™ processors, plus choice of NVIDIA® or Intel® graphics
- Multiple display options, including WQXGA & X-Rite colour calibration
- Next-gen memory & storage for seamless multitasking
- Superb connectivity, including Intel® WiFi 6E & Intel® Thunderbolt™ 4
- Includes number pad, glass-like touchpad, & webcam privacy shutter
The freedom to work from anywhere
Built to perform superbly in the field or office, the ThinkPad P16s enables everyone from engineers to students and medical professionals to be innovative, anywhere. This light, powerful mobile workstation boasts up to Intel® Core™ i7 processors and comes with a choice of NVIDIA® discrete graphics or integrated Intel® graphics. It’s also ISV certified and breezes through graphics-intensive software like AutoCAD® and SolidWorks®.
Be inspired, from the outside in
Designed with enhanced usability including a secure fingerprint reader, full numeric keypad, and wide touchpad, ThinkPad P16s is the ideal for whether you're collaborating in the office, on site, or with clients. Available with a choice of screen options, including QHD+ with X-Rite Factory Colour Calibration, touch display, and low-blue light technology.
Configurable, durable, & reliable
With up to 48GB of lightning-quick DDR4 memory and up to 2TB of next-gen PCIe Gen4 NMVe storage, the ThinkPad P16s can be configured to meet your exact needs. Together with its array of advanced ThinkShield security features and ability to meet stringent US military tests for durability, ruggedness, and reliability, this mobile workstation enables you to work in almost any environment.
All you need to be connected, or not
Even with jaw-dropping performance, the ThinkPad P16s is still surprisingly light and slim, weighing from just 1.68 kgs and 20.5mm / 0.8" thin. It offers robust connectivity, including two Intel® Thunderbolt™ 4 ports, plus HDMI and USB-A 3.2 connectors. It also has a webcam privacy shutter, so you can physically turn the FHD camera off and on.
We’ve got your back
When you spend hours on business-critical projects, it’s essential to know that all your hard work and efforts are backed by the best. That’s why, the ThinkPad P16s comes with ThinkShield—our comprehensive portfolio of end-to-end protection and customizable security features, including advanced data encryption and biometric technology.
| Design |
|---|
| Housing material |
Carbon fibre, Glass fibre, Polycarbonate (PC), Polyphenylene sulfide (PPS) |
| Form factor |
Clamshell |
| Colour name |
Black |
| Product colour |
Black |
| Product type |
Mobile workstation |
| Display |
|---|
| RGB colour space |
NTSC |
| Colour gamut |
45% |
| Display brightness |
300 cd/m² |
| Anti-glare screen |
Yes |
| LED backlight |
Yes |
| Native aspect ratio |
16:10 |
| Panel type |
IPS |
| HD type |
WUXGA |
| Touchscreen |
No |
| Display resolution |
1920 x 1200 pixels |
| Display diagonal |
40.6 cm (16") |
| Processor |
|---|
| Configurable TDP-down |
20 W |
| Motherboard chipset |
Intel SoC |
| Processor cache |
18 MB |
| Processor cores |
12 |
| Processor boost frequency |
4.7 GHz |
| Processor model |
i7-1260P |
| Processor generation |
12th gen Intel® Core™ i7 |
| Processor family |
Intel® Core™ i7 |
| Processor manufacturer |
Intel |
| Memory |
|---|
| Memory channels |
Dual-channel |
| Maximum internal memory |
48 GB |
| Memory slots |
1x SO-DIMM |
| Memory clock speed |
3200 MHz |
| Memory form factor |
On-board |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
16 GB |
| Storage |
|---|
| Card reader integrated |
No |
| Optical drive type |
No |
| SSD form factor |
M.2 |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
512 GB |
| Storage media |
SSD |
| Total storage capacity |
512 GB |
| Graphics |
|---|
| Discrete graphics memory type |
GDDR6 |
| Discrete graphics card memory |
4 GB |
| On-board graphics card model |
Intel Iris Xe Graphics |
| On-board graphics card family |
Intel Iris Xe Graphics |
| On-board GPU manufacturer |
Intel |
| Discrete graphics card model |
NVIDIA Quadro T550 |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Audio |
|---|
| Number of microphones |
2 |
| Built-in microphone |
Yes |
| Number of built-in speakers |
2 |
| Audio system |
Dolby Audio |
| Audio chip |
Realtek ALC3287 |
| Camera |
|---|
| Privacy type |
Privacy shutter |
| Privacy camera |
Yes |
| Infrared (IR) camera |
Yes |
| Front camera resolution |
1920 x 1080 pixels |
| Front camera |
Yes |
| Network |
|---|
| WWAN |
Installed |
| Near Field Communication (NFC) |
No |
| Bluetooth version |
5.2 |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer |
Intel |
| Antenna type |
2x2 |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Mobile network connection |
No |
| Ports & interfaces |
|---|
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| USB Power Delivery |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Combo headphone/mic port |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| HDMI version |
2.1 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Keyboard |
|---|
| Spill-resistant keyboard |
Yes |
| Keyboard backlit |
Yes |
| Numeric keypad |
Yes |
| Keyboard language |
UK English |
| Pointing device |
ThinkPad UltraNav |
| Software |
|---|
| Recovery operating system |
Windows 10 Pro |
| Operating system language |
English |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Processor special features |
|---|
| Intel Flex Memory Access |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Execute Disable Bit |
Yes |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Battery |
|---|
| Battery capacity |
52.5 Wh |
| Battery technology |
Lithium Polymer (LiPo) |
| Power |
|---|
| AC adapter power |
100 W |
| Security |
|---|
| Password protection type |
BIOS, Power on, Supervisor, SSD |
| Password protection |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Windows Hello |
Yes |
| Fingerprint reader |
Yes |
| Smart card reader |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating temperature (T-T) |
5 - 35 °C |
| Certificates |
|---|
| Certification |
EPEAT GoldENERGY STAR 8.0TCO Certified 9.0RoHS compliant |
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, TCO |
| Weight & dimensions |
|---|
| Height |
20.8 mm |
| Depth |
255.5 mm |
| Width |
361.9 mm |
| Weight |
1.68 kg |
| General |
|---|
| Product Family |
ThinkPad |
| Product Series |
P |
