MSI's flagship MEG series exemplifies relentless innovation, continuously setting new benchmarks in the gaming hardware space. This trailblazing series employs pioneering technology to push the boundaries of gaming, consistently leading with innovations that redefine what gamers expect.

Cooling
Fan diameter	13.5 cm
Design
80 PLUS certification	80 PLUS Titanium
Product colour	Black
Fan diameter	13.5 cm
Power
Total power	1600 W
AC input voltage	100 - 240 V
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	120 W
Combined power (+12V)	1600 W
Combined power (+5V)	120 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	22 A
Max output current (+12V)	133.3 A
Max output current (+5V)	22 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Efficiency	94%
Ports & interfaces
Motherboard power connector	24-pin ATX
Number of SATA power connectors	8
Peripheral (Molex) power connectors (4-pin)	8
EPS power connector (8-pin)	No
PCI Express power connectors (6+2 pin)	9
Cabling type	Fully-Modular
EPS power connector (4+4 pin)	Yes
PCI Express power connectors (16-pin)	2
Performance
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Titanium
Purpose	PC
Bearing technology	DBB
Weight & dimensions
Width	190 mm
Depth	150 mm
Height	86 mm
Certificates
80 PLUS certification	80 PLUS Titanium
