NVIDIA GeForce RTX 4070 SUPER, 12GB GDDR6X, 192 bit, PCI Express x16 4.0, 1 x HDMI (2.1a), 3 x DP (1.4a), CUDA, DirectX 12 Ultimate, OpenGL 4.6, 220W
The ZOTAC GAMING GeForce RTX 4070 SUPER Twin Edge OC 12GB GDDR6X is a compact and powerful graphics card, featuring the NVIDIA Ada Lovelace architecture and an aerodynamic-inspired design. With a reduced dual slot size, it's an excellent choice for those who want to build a SFF gaming PC capable of impressive framerate and performance in the latest title releases.
| Processor |
|---|
| Maximum displays per videocard |
4 |
| Processor boost clock speed |
2490 MHz |
| CUDA cores |
7168 |
| CUDA |
Yes |
| Maximum resolution |
7680 x 4320 pixels |
| Graphics processor |
GeForce RTX 4070 SUPER |
| Graphics processor family |
NVIDIA |
| Memory |
|---|
| Data transfer rate |
21 Gbit/s |
| Memory bus |
192 bit |
| Graphics card memory type |
GDDR6X |
| Discrete graphics card memory |
12 GB |
| Ports & interfaces |
|---|
| DisplayPort version |
1.4a |
| HDMI version |
2.1a |
| DisplayPorts quantity |
3 |
| HDMI ports quantity |
1 |
| Interface type |
PCI Express x16 4.0 |
| Performance |
|---|
| Dual Link DVI |
No |
| HDCP |
Yes |
| HDCP version |
2.3 |
| OpenGL version |
4.6 |
| Shader model version |
No |
| DirectX version |
12 Ultimate |
| TV tuner integrated |
No |
| Design |
|---|
| Product colour |
Black |
| Illumination |
Yes |
| Illumination colour |
Blue, Green, Red |
| Number of slots |
2 |
| Form factor |
Full-Height/Half-Length (FH/HL) |
| Bracket height |
Full-Height (FH) |
| Number of fans |
2 fan(s) |
| Cooling type |
Active |
| Power |
|---|
| Power consumption (typical) |
220 W |
| Supplementary power connectors |
2x 8-pin |
| Minimum system power supply |
750 W |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Weight & dimensions |
|---|
| Depth |
234.1 mm |
| Height |
123.5 mm |
| Width |
40.2 mm |
| Packaging data |
|---|
| Package type |
Box |
