Seagate Cheetah - 15K RPM SAS 3.5" HDD - 600 GB
The higher performance and capacity of Seagate Cheetah 15K.7 drives reduce storage costs per GB and increase capacity per watt. The drive has the industry’s highest reliability rating, reducing drive replacement costs. The Cheetah 15K.7 drive includes Seagate PowerTrim technology, which dynamically optimizes drive power consumption at all levels of activity.
- Third-generation perpendicular recording for maximum capacity
- Unprecedented performance with a 16 percent increase in sustained data rate over the last generation, up to 171 MB/sec.
- Industry’s highest 3.5-inch drive reliability at 1.6-million-hours MTBF.
- Seagate proprietary PowerTrim technology provides up to 21 percent improvement over the last generation in watts/GB at idle.
- Advanced read/write technology delivers unrecoverable error rate of 1x10E16 and AFR of 0.55 percent
- Available in 4Gb/s FC or 6Gb/s SAS interfaces
| Features | |
|---|---|
| Mean time between failures (MTBF) | 1600000 h |
| Average latency | 2 ms |
| Read seek time | 3.4 ms |
| Write seek time | 3.9 ms |
| HDD number of heads | 8 |
| Storage drive buffer size | 16 MB |
| Component for | Server/workstation |
| Type | HDD |
| Interface | SAS |
| HDD speed | 15000 RPM |
| HDD capacity | 600 GB |
| HDD size | 3.5" |
| Power | |
|---|---|
| Operating voltage | 5 / 12 V |
| Power consumption (idle) | 11.68 W |
| Power consumption (typical) | 16.35 W |
| Operational conditions | |
|---|---|
| Non-operating shock | 300 G |
| Operating shock | 60 G |
| Non-operating vibration | 3 G |
| Operating vibration | 1 G |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 5 - 55 °C |
| General | |
|---|---|
| Product Family | Cheetah |
| Weight & dimensions | |
|---|---|
| Weight | 686 g |
| Height | 25.4 mm |
| Depth | 146.5 mm |
| Width | 101.6 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84717050 |
