Monitor 172B9T LCD monitor with SmoothTouch

A sturdy water- and dust-resistant touch-screen monitor for flexible use anywhere, with articulating stand to fit angles you need. Offering simple and intuitive use across applications, greatly boosts productivity.

SmoothTouch display for natural, fluid touch response
This Philips display uses Projected capacitive 10 point touch technology for fluid response. You can fully utilize the new capabilities of touch based applications, and bring your older applications to life. Touch-type with 10 fingers, or play exciting interactive games with your friends. Collaborate with colleagues interactively at work or school environment and increase your productivity and efficiency.

Monitor front surface meets IP65 for water & dust resistance
For less than perfect environments, you need a monitor that's designed to hold up to the splashes of water and dust that happen in the everyday world. Ingress Protection (IP) ratings defined in international standard IEC/EN 60529, are used to define levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies and moisture. This Philips display meets international the IP rating for water and dust resistance, it will hold up to water splashes and dust that happen in the everyday world.

LowBlue Mode for easy on-the-eyes productivity
Studies have shown that just as ultra-violet rays can cause eye damage, shortwave length blue light rays from LED displays can cause eye damage and affect vision over time. Developed for wellbeing, Philips LowBlue Mode setting uses a smart software technology to reduce harmful shortwave blue light.

Less eye fatigue with Flicker-free technology
Due to the way brightness is controlled on LED-backlit screens, some users experience flicker on their screen which causes eye fatigue. Philips Flicker-free Technology applies a new solution to regulate brightness and reduce flicker for more comfortable viewing.

SmartContrast for rich black details
SmartContrast is a Philips technology that analyzes the contents you are displaying, automatically adjusting colors and controlling backlight intensity to dynamically enhance contrast for the best digital images and videos or when playing games where dark hues are displayed. When Economy mode is selected, contrast is adjusted and backlighting fine-tuned for just-right display of everyday office applications and lower power consumption.

DisplayPort connection for maximum visuals
DisplayPort is a digital link from PC to Monitor without any conversion. With higher capabilities than DVI standard, it is fully capable to support up to 15meter cables and 10.8 Gbps/sec data transfer. With this high performance and zero latency, you get the fastest imaging and refresh rates - making DisplayPort the best choice for not only general office or home use, but also for the demanding gaming and movies, video editing and more. It also keeps interoperability in mind via use of various adapters.

HDMI ensures universal digital connectivity
An HDMI-ready device has all the required hardware to accept High-Definition Multimedia Interface (HDMI) input. A HDMI cable enables high-quality digital video and audio all transmitted over a single cable from a PC or any number of AV sources (including set-top boxes, DVD players, A/V receivers and video cameras).

Display
Colour gamut standard	sRGB
Display sRGB	Yes
3D	No
NTSC coverage (typical)	87%
sRGB coverage (typical)	103%
Colour gamut	87%
Surface hardness	7H
DDC/CI	Yes
Display diagonal (metric)	43.2 cm
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	30 - 85 kHz
Viewable size, vertical	27 cm
Viewable size, horizontal	33.8 cm
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 85 kHz
Pixel density	96 ppi
Pixel pitch	0.264 x 0.264 mm
Display number of colours	16.78 million colours
Viewing angle, vertical	160°
Viewing angle, horizontal	170°
Maximum refresh rate	60 Hz
Dynamic contrast ratio marketing name	SmartContrast
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Aspect ratio	5:4
Supported graphics resolutions	1280 x 1024 (SXGA)
Screen shape	Flat
Display surface	Gloss
Response time	1 ms
Display brightness (typical)	250 cd/m²
Number of simultaneous touchpoints	10
Touchscreen technology	Projected capacitive system
Touchscreen type	Capacitive
Backlight type	W-LED
Panel type	TN
HD type	SXGA
Touchscreen	Yes
Display technology	LCD
Native aspect ratio	5:4
Display resolution	1280 x 1024 pixels
Display diagonal	43.2 cm (17")

Performance
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Low Blue Light technology	Yes
Flicker-free technology	Yes
Component video sync	Separate sync, Sync-on-green (SOG)
AMD FreeSync	No
NVIDIA G-SYNC	No

Multimedia
RMS rated power	2 W
Number of speakers	2
Built-in camera	No
Built-in speaker(s)	Yes

Design
Certification	CB, CE Mark, FCC Class B, SEMKO, UKRAINIAN, ICES-003, TUV/GS, TUV Ergo, CU-EAC, EAEU RoHS
Heavy metals free	Hg (mercury)
International Protection (IP) code	IP65
Feet colour	Black
Front bezel colour	Black
Product colour	Black
Market positioning	Home

Ports & interfaces
HDCP	Yes
PC Audio in	Yes
Headphone out	Yes
Audio input	Yes
DisplayPort version	1.2
DisplayPorts quantity	1.2
HDMI version	1.4
HDMI ports quantity	1.4
HDMI	Yes
DVI-D ports quantity	1
DVI port	Yes
VGA (D-Sub) ports quantity	1
USB Touch port	Yes
USB Type-A downstream ports quantity	2
Number of upstream ports	1
USB upstream port type	USB Type-B
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Built-in USB hub	Yes

Ergonomics
Tilt adjustment	Yes
LED indicators	Operation, Stand-by
Plug and Play	Yes
Palm rejection area	30 x 30 mm
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian
On Screen Display (OSD)	Yes
Tilt angle range	-5 - 90°
Height adjustment	7.6 cm
Height adjustment	Yes
Cable lock slot type	Kensington
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
VESA mounting	Yes

Power
External power adapter	Yes
Energy efficiency scale	A to G
Power supply type	External
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Power consumption (PowerSave)	7.7 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.3 W
Power consumption (typical)	9.14 W
Energy consumption (SDR) per 1000 hours	10 kWh
Energy efficiency class (SDR)	D

Operational conditions
Non-operating altitude	0 - 12192 m
Operating altitude	0 - 3658 m
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C

Packaging content
Bundled software	SmartControl
Manual	Yes
Cables included	VGA, HDMI, DisplayPort, USB Type-A to USB Type-B, Audio (3.5mm), AC
Stand included	Yes

Weight & dimensions
Weight (without stand)	3.26 kg
Height (without stand)	322 mm
Depth (without stand)	45 mm
Width (without stand)	376 mm
Weight (with stand)	6.24 kg
Height (with stand)	399 mm
Depth (with stand)	227 mm
Width (with stand)	376 mm

Packaging data
Package type	Box
Package weight	7.95 kg
Package height	420 mm
Package depth	159 mm
Package width	445 mm

Sustainability
European Product Registry for Energy Labelling (EPREL) code	388185
Doesn't contain	PVC/BFR, Mercury
Sustainability certificates	ENERGY STAR, TCO

Logistics data
Harmonized System (HS) code	85285210

Technical details
Compliance certificates	RoHS, WEEE

Other features
Recommended resolution	1280 x 1024 @ 60 Hz
Touch method	Stylus, Finger, Glove
Picture enhancement	SmartImage
Regulatory Approvals	CB; CE Mark; FCC Class B; SEMKO; UKRAINIAN; ICES-003; TUV/GS; TUV Ergo; CU-EAC; EAEU RoHS
Mean time between failures (MTBF)	70000 h
Folding angle	70°
Recyclable packaging material	100%
EasyRead mode	Yes
Display viewable area (HxV)	337.9 x 270.3 mm
Multi-touch	Yes
Mobile operating systems supported	Android 7.1, Android 7.0, Android 6.0, Android 5.0, Android 4.4
TV tuner integrated	No
On/off switch	Yes
