MSI Titan 18 HX AI A2XWIG-007UK Intel Core Ultra 9 285HX Laptop 45.7 cm (18") UHD+ 64 GB DDR5-SDRAM 4 TB SSD NVIDIA GeForce RTX 5080 Wi-Fi 7 (802.11be) Windows 11 Pro Black

Key Features

• Processor:
• Total storage capacity:
• Screen display size:
• Resolution:
• Operating system:

Overview

Design
Colour name	Core Black
Product type	Laptop
Market positioning	Gaming
Form factor	Clamshell
Product colour	Black
Original brand name	MSI
Country of origin	China
Display
HD type	UHD+
Panel type	Mini LED
Touchscreen	No
Display resolution	3840 x 2400 pixels
Display diagonal	45.7 cm (18")
Maximum refresh rate	120 Hz
RGB colour space	DCI-P3
Colour gamut	100%
Native aspect ratio	16:10
Processor
Processor generation	Intel Core Ultra (Series 2)
Processor cache	36 MB
Processor model	285HX
Processor boost frequency	5.5 GHz
Processor cores	24
Processor threads	24
Motherboard chipset	Intel HM870
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor base power	55 W
Maximum turbo power	160 W
Efficient-core base frequency	2.1 GHz
Performance-core base frequency	2.8 GHz
Efficient-core Max Turbo Frequency	4.6 GHz
Performance-core Max Turbo Frequency	5.5 GHz
Performance cores	8
Efficient cores	16
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	36 TOPs
NPU performance up to	13 TOPs
GPU performance up to	8 TOPs
Memory
Internal memory	64 GB
Memory layout (slots x size)	2 x 32 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	6400 MHz
Memory slots	2x SO-DIMM
Maximum internal memory	96 GB
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	2
SSD capacity	2 TB
SSD interface	PCI Express 4.0
Card reader integrated	Yes
Compatible memory cards	SD
Total storage capacity	4 TB
Total SSDs capacity	4 TB
NVMe	Yes
Graphics
Discrete graphics card	Yes
Discrete graphics card memory	16 GB
On-board graphics card family	Intel Graphics
On-board graphics card	Yes
On-board graphics card model	Intel Graphics
Discrete graphics card model	NVIDIA GeForce RTX 5080
Discrete graphics memory type	GDDR7
Discrete GPU manufacturer	NVIDIA
On-board GPU manufacturer	Intel
Audio
Number of built-in speakers	4
Speaker power	2 W
Camera
Front camera	Yes
Front camera resolution	1920 x 1080 pixels
Video capturing speed	30 fps
Privacy camera	Yes
Privacy type	Privacy shutter
Front camera HD type	Full HD
Infrared (IR) camera	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN controller model	Killer Wi-Fi BE1750x
Wi-Fi standards	Wi-Fi 7 (802.11be)
Ethernet LAN	Yes
Ethernet LAN data rates	2500 Mbit/s
Bluetooth	Yes
Bluetooth version	5.4
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB Type-C DisplayPort Alternate Mode	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 5 ports quantity	2
Intel® Thunderbolt 5	Yes
Performance
Motherboard chipset	Intel HM870
Keyboard
Pointing device	Touchpad
Numeric keypad	Yes
Keyboard backlit	Yes
Keyboard backlit colour	RGB
Copilot key	Yes
Software
Operating system installed	Windows 11 Pro
Technical details
Market positioning	Gaming
Form factor	Clamshell
Product colour	Black
Discrete graphics card memory	16 GB
Sustainability certificates	EPEAT Silver
Warranty period	2 year(s)
Battery
Battery technology	Lithium Polymer (LiPo)
Number of battery cells	4
Battery capacity	99.99 Wh
Power
AC adapter power	400 W
USB Power Delivery (USB PD)	Yes
Security
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Fingerprint reader	Yes
Cable lock slot	Yes
Trusted Platform Module (TPM) version	2.0
Sustainability
Sustainability certificates	EPEAT Silver
Weight & dimensions
Width	404 mm
Depth	307 mm
Height	32 mm
Weight	3.6 kg
Packaging data
Package weight	4 kg
Package width	483 mm
Package height	377 mm
Package depth	114 mm
Package volume	33732784 cm³
Features
Country of origin	China
Supplier features
Country of origin	China
Other features
WLAN controller model	Killer Wi-Fi BE1750x
On-board graphics card	Yes
Country of origin	China
Warranty period	2 year(s)

Standing proudly as a leader in gaming innovation, the Titan 18 HX AI has reached new heights, pushing the limits of performance with its top-tier, all-encompassing features. Its advanced cooling system delivers unmatched power, ensuring smooth performance even during the most demanding tasks. Encased in a strong yet lightweight magnesium-aluminum alloy chassis, this flagship device blends durability with portability, making it the top choice for gamers and creators aiming for excellence.
