60.5cm (23.8") WQHD 2560 x 1440 W-LED IPS, 16:9, 300cd/m², 16.78M, 6ms, 178°/178°, 1000:1
Everyday tasks are a breeze with the efficiency of the ThinkVision T24H-20 monitor. A well-designed QHD 2560 x 1440 resolution screen, multiple ports, and wide color gamut make it one of the most sought after 23.8-inch commercials displays available. Boost your productivity with a dual or multi-monitor setup taking advantage of the 3-side NearEdgeless bezels that offer a seamless, virtually borderless experience. It has a specially engineered panel to reduce glare, an ergonomic stand for improved customization, and a VESA mount for wall hanging. Maximize your desk space with the USB Type-C one-cable solution that comes integrated with Smart Power for better connectivity and power efficiency.
| Display |
|---|
| Colour gamut standard |
sRGB |
| sRGB coverage (typical) |
99% |
| Colour depth |
8 bit |
| Viewable size, vertical |
29.6 cm |
| Viewable size, horizontal |
52.7 cm |
| Pixel density |
123 ppi |
| Pixel pitch |
0.2058 x 0.2058 mm |
| Response time (fast) |
4 ms |
| Display number of colours |
16.78 million colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
60 Hz |
| Contrast ratio (dynamic) |
3000000:1 |
| Contrast ratio (typical) |
1000:1 |
| Supported graphics resolutions |
2560 x 1440 |
| Screen shape |
Flat |
| Response time |
6 ms |
| Display brightness (typical) |
300 cd/m² |
| Backlight type |
W-LED |
| Panel type |
IPS |
| HD type |
Quad HD |
| Touchscreen |
No |
| Display technology |
LED |
| Native aspect ratio |
16:9 |
| Display resolution |
2560 x 1440 pixels |
| Display diagonal |
60.5 cm (23.8") |
| Performance |
|---|
| Low Blue Light technology |
Yes |
| Multimedia |
|---|
| Built-in camera |
No |
| Built-in speaker(s) |
No |
| Design |
|---|
| Certification |
CCC, TCO 8.0, TCO Edge 2.0 |
| Feet colour |
Black |
| Front bezel colour |
Black |
| Colour name |
Raven Black |
| Product colour |
Black |
| Ports & interfaces |
|---|
| Audio output |
Yes |
| Audio input |
No |
| DisplayPort version |
1.2 |
| DisplayPorts quantity |
1 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| HDMI |
Yes |
| DVI port |
No |
| USB Power Delivery up to |
75 W |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Type-A downstream ports quantity |
4 |
| Number of upstream ports |
1 |
| USB upstream port type |
USB Type-C |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Built-in USB hub |
Yes |
| Ergonomics |
|---|
| Tilt adjustment |
Yes |
| Number of OSD languages |
8 |
| On Screen Display (OSD) |
Yes |
| Tilt angle range |
-5 - 35° |
| Swivel angle range |
-45 - 45° |
| Swivelling |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Height adjustment |
15 cm |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Power |
|---|
| AC input frequency |
47/63 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (off) |
0.3 W |
| Power consumption (typical) |
23 W |
| Packaging content |
|---|
| Cables included |
AC, USB Type-C to USB Type-C |
| Stand included |
Yes |
| Weight & dimensions |
|---|
| Bezel width (bottom) |
2.41 cm |
| Bezel width (top) |
2 mm |
| Bezel width (side) |
2 mm |
| Weight (without stand) |
3.85 kg |
| Height (without stand) |
325.7 mm |
| Depth (without stand) |
44.6 mm |
| Width (without stand) |
539.8 mm |
| Weight (with stand) |
6.18 kg |
| Height (with stand) |
420 mm |
| Depth (with stand) |
205 mm |
| Width (with stand) |
539.8 mm |
| Packaging data |
|---|
| Package weight |
8.1 kg |
| Package height |
620 mm |
| Package depth |
149 mm |
| Package width |
423 mm |
| Sustainability |
|---|
| Sustainability certificates |
EPEAT Silver, ENERGY STAR |
| General |
|---|
| Product Family |
ThinkVision |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Technical details |
|---|
| Compliance certificates |
RoHS |
