14" 16:10 In-Plane Switching 2240 x 1400, 0.135x0.135 mm, 189 dpi, 1500:1, 300 cd/m²

ThinkVision M14d has 14" screen, 16:10 aspect ratio, 104 PPI, 2240 x 1400 resolution screen with 100% sRGB colour gamut which ensure rich, clear imagery and true-to-life colours. M14d comes with two Type-C ports for quick upstream and downstream connectivity, allowing you to connect your notebook effortlessly. In addition, the Type-C ports have the ‘power pass-through’ feature that allows you to power the monitor and charges your notebook simultaneously. The mobile monitor also has the Natural Low Blue Light technology which reduces the harmful blue light to make viewing a comfortable and stress-free experience without colour distortion.

The all-out visual performer

The ThinkVision M14d Mobile Monitor has a 2.2K, 104 PPI, 2240 x 1400 resolution screen with IPS panel that offers excellent, sharp performance, and superb visibility from wide viewing angles. Its 16:10 aspect ratio and its ‘mirror and extend’ feature means that it is perfectly aligned with the viewing format of your 16:10 notebook. This mobile monitor comes with a 100% sRGB color gamut and 105% sRGB color space which is consistent with notebooks and displays rich, true-to-life colors. No wonder it adapts easily to your mobile lifestyle and gives your personal productivity a big boost.

Power pass-through for extra convenience

The ThinkVision M14d Mobile Monitor will delight you with its connectivity and convenience. This monitor comes with 2 x USB Type-C ports with up to 65W power pass-through. This unique feature means you can power your ThinkVision M14d Mobile Monitor and charge your notebook simultaneously while keeping your desk clutter-free. Now, you don’t have to worry about charging multiple devices. Just charge your notebook and connect your mobile monitor for uninterrupted performance.

Portable & comfortable

Weighing in at less than 600 grams, this slim, lightweight, ultra-portable monitor’s 14-inch screen is just 4.6 mm thick, making it very easy to carry. The ThinkVision M14d Mobile Monitor also comes with Natural Low Blue Light technology that protects your eyes from harmful blue light enables you to have a strain-free viewing experience without color distortion. Even when you are viewing it for long hours. Its Mount feature helps you adjust the monitor for enhanced ergonomics and comfort. In addition, the ThinkVision M14d comes with a height adjustment support feature that further enhances the user experience.

Display
sRGB coverage (typical)	100%
RGB colour space	sRGB
Colour depth	8 bit
Viewable size, vertical	18.9 cm
Viewable size, horizontal	30.1 cm
Pixel density	104 ppi
Pixel pitch	0.135 x 0.135 mm
Response time (fast)	6 ms
Display number of colours	16.7 million colours
Viewing angle, vertical	178°
Viewing angle, horizontal	178°
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1500:1
Screen shape	Flat
Anti-glare screen	Yes
Response time	8 ms
Display brightness (typical)	300 cd/m²
Display brightness (peak)	375 cd/m²
Backlight type	W-LED
Panel type	IPS
HD type	2.2K
Touchscreen	No
Display technology	LED
Native aspect ratio	16:10
Display resolution	2240 x 1400 pixels
Display diagonal	35.6 cm (14")

Performance
Low Blue Light technology	Yes

Multimedia
Built-in camera	No
Built-in speaker(s)	No

Design
Certification	Energy Star Certified, EPEAT Silver, RoHSEyesafe Display, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Low Blue Light, TÜV Rheinland Flicker Free
Product colour	Black

Ports & interfaces
HDMI	No
USB Type-C DisplayPort Alternate Mode	Yes
USB Type-C downstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
Number of upstream ports	1
USB upstream port type	USB Type-C
Built-in USB hub	Yes

Ergonomics
Tilt adjustment	Yes
On Screen Display (OSD)	Yes
Tilt angle range	-5 - 95°
Height adjustment	1.1 cm
Height adjustment	Yes
Cable lock slot type	Kensington
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
VESA mounting	Yes

Power
Power supply type	External
Power consumption (off)	0.5 W
Power consumption (max)	7.5 W
Power consumption (typical)	6 W

Packaging content
Quick start guide	Yes
Cables included	USB Type-C
Stand included	Yes

Weight & dimensions
Bezel width (bottom)	1.89 cm
Bezel width (top)	4.9 mm
Bezel width (side)	4.9 mm
Weight (without stand)	400 g
Height (without stand)	215.3 mm
Depth (without stand)	4.6 mm
Width (without stand)	314.4 mm
Weight (with stand)	600 g
Depth (with stand)	106.4 mm
Width (with stand)	314.4 mm

Packaging data
Package type	Box
Package weight	1.8 kg
Package height	277 mm
Package depth	76 mm
Package width	384 mm

General
Product Family	ThinkVision
