23.8" 16:9 In-Plane Switching 1920 x 1080, 0.275 x 0.275 mm, 93 dpi, 1000:1, 250 cd/m²

The ThinkVision E22-28 is a user-oriented device, designed with modern workforce requirements in mind. Boost productivity with this 21.5-inch Full-HD display with a 4 ms response time in extreme mode that delivers clear and accurate visuals, no matter the task. The ports on offer—HDMI, DP, and VGA—allow for versatile connectivity. Most of all, its ergonomically designed stand allows for complete customisation in terms of lift, tilt, pivot, and swivel which not only optimises office space, but also ensures you experience minimal fatigue while on the job.

Consistent Visuals

Full-HD resolution with an In-Plane Switching display delivers clear visuals even at different viewing angles. The 3-side NearEdgeless bezels allow users to set up a multi-screen workplace for efficient multitasking and collaboration. Moreover, TÜV Rheinland Eye Comfort certification ensures minimal eye strain and fatigue.

Seamless Interfacing

Catering to the needs of the new-gen workforce, the ThinkVision E24-28 offers multiple connectivity options such as DP, VGA, and HDMI, enabling them to collaborate and engage with their peers efficiently. The built-in speakers on this monitor provide decent audio clarity, enhancing the productivity in meetings.

Crafted for Convenience

Designed keeping its users in mind, the ThinkVision E24-28 provides a lift range of 155 mm, tilt angles of -5° / 22°, swivel angles of ± 360°, and a pivot range of ± 90°, giving employees the option to customize the monitor any way they want, minimizing neck and back strains and aches. The 100 mm VESA mount support offers flexible mounting options to optimize the available workspace.

Display
NTSC coverage (typical)	72%
Pixel density	93 ppi
Pixel pitch	0.2745 x 0.2745 mm
Response time (fast)	4 ms
Display number of colours	16.7 million colours
Viewing angle, vertical	178°
Viewing angle, horizontal	178°
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1000:1
Aspect ratio	16:9
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Screen shape	Flat
Response time	6 ms
Display brightness (typical)	250 cd/m²
Backlight type	W-LED
Panel type	IPS
HD type	Full HD
Touchscreen	No
Display technology	LED
Native aspect ratio	16:9
Display resolution	1920 x 1080 pixels
Display diagonal	60.5 cm (23.8")

Performance
AMD FreeSync	No
NVIDIA G-SYNC	No

Multimedia
RMS rated power	3 W
Number of speakers	2
Built-in camera	No
Built-in speaker(s)	Yes

Design
Colour name	Raven Black
Product colour	Black
Market positioning	Business

Ports & interfaces
DisplayPort version	1.2
DisplayPorts quantity	1
HDMI version	1.4
HDMI ports quantity	1
HDMI	Yes
VGA (D-Sub) ports quantity	1
Built-in USB hub	No

Ergonomics
Tilt adjustment	Yes
On Screen Display (OSD)	Yes
Swivel angle range	-360 - 360°
Swivelling	Yes
Pivot angle	-90 - 90°
Pivot	Yes
Height adjustment	Yes
Cable lock slot type	Kensington
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
VESA mounting	Yes

Power
Power consumption (off)	0.5 W
Power consumption (max)	24 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W

Packaging content
Quick start guide	Yes
Cables included	AC, HDMI
Stand included	Yes

Weight & dimensions
Bezel width (bottom)	2.09 cm
Bezel width (top)	3.1 mm
Bezel width (side)	3.1 mm
Weight (without stand)	3.1 kg
Height (without stand)	326.4 mm
Depth (without stand)	41.7 mm
Width (without stand)	541.8 mm
Weight (with stand)	4.8 kg
Height (with stand)	462.5 mm
Depth (with stand)	178.6 mm
Width (with stand)	541.8 mm

Packaging data
Package type	Box
Package weight	5.7 kg
Package height	397 mm
Package depth	145 mm
Package width	638 mm

Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Silver, RoHS, TCO
Sustainability compliance	Yes

General
Product Family	ThinkVision

Logistics data
Harmonized System (HS) code	85285210
