14" 16:9 In-Plane Switching 1920 x 1080, 0.1611x0.1611 mm, 157 dpi, 700:1, 300 cd/m²

Scale new heights of productivity, flexibility, and style with a touch-enabled mobile monitor. The slim and light ThinkVision M14T is a 14-inch Full-HD display that provides you with an extra screen whenever you need it. With 10-point touch functionality, enjoy the freedom to design, animate, present, and annotate on an intuitive monitor interface. More than just a display, the M14T comes with a pressure-sensitive active pen for precise sketching and easy navigation, as well as a customised sleeve for protection and an L-shaped dongle for vertical deployment and better cable management. This compact USB-C Hub monitor with two USB-C ports works seamlessly with not only the Lenovo Think family laptops but also with your other compatible USB-C devices, like your smartphone. The monitor offers ease of use, especially while working on the go. Connect, present, pitch, and create with conviction on the M14t—at the office or on the go.

SEE MORE EVERYWHERE YOU GO
Built for mobile professionals, the M14T’s 14" Full-HD IPS panel display with super-narrow bezels ensures crisp and accurate visuals with impressive viewing angles, making it ideal for presentations. This sleek ultra-portable monitor with tilt function (-5° / 90°) and a height-adjustable stand (up to 11 mm) allows users to work in a flexible and comfortable viewing position in any work environment. Get a clear view of the display, whether you are outdoors or in an office, with 300 nits brightness capability. Moreover, the TÜV Rheinland Low Blue Light technology lets you work with minimal eyestrain.

DELIVER AS ONLY YOU CAN
Drag, draw, annotate, and collaborate, no matter where you are. The ThinkVision M14T is 10-point touch-enabled for an intuitive interactive experience even on the go, allowing you to create with a personal touch. It comes along with an active digital pen that supports 4096 levels of pressure, so you can draw and sketch with unmatched precision. Switch your view in no time with auto-rotation sensors that don’t require software or driver installation. Additionally, an intuitive on-screen-display (OSD) menu enables easy access to brightness, contrast, and rotation settings.

CONNECT BETTER, WORK EASIER
Built with an innovative dual USB-C design, the M14T can duplicate or extend your screen—be it your smartphone or laptop—so you’re always productive. With data, power, and media capabilities of USB-C, you can create a presentation, transfer data to a hard drive, and enjoy the unique power pass-through function. With dual USB-C port, the power pass-through function supplies power to the M14t and the compatible USB-C device connected to the monitor simultaneously via one AC/DC adapter. Enjoy the option of a vertical display setup and better cable management for a clean, easy desktop setup with the L-shaped dongle.

Display
NTSC coverage (typical)	72%
RGB colour space	NTSC
Colour depth	8 bit
Digital vertical frequency	50 - 75 Hz
Digital horizontal frequency	30 - 90 kHz
Viewable size, vertical	17.3 cm
Viewable size, horizontal	30.9 cm
Pixel density	157 ppi
Pixel pitch	0.1611 x 0.1611 mm
Response time (fast)	6 ms
Display number of colours	16.78 million colours
Viewing angle, vertical	178°
Viewing angle, horizontal	178°
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	700:1
Supported graphics resolutions	1920 x 1080 (HD 1080)
Screen shape	Flat
Response time	8 ms
Display brightness (typical)	300 cd/m²
Backlight type	W-LED
Panel type	IPS
HD type	Full HD
Touchscreen	Yes
Display technology	LED
Native aspect ratio	16:9
Display resolution	1920 x 1080 pixels
Display diagonal	35.6 cm (14")

Performance
Low Blue Light technology	Yes
AMD FreeSync	No
NVIDIA G-SYNC	No

Multimedia
Built-in camera	No
Built-in speaker(s)	No

Design
Certification	TÜV Rheinland Low Blue Light, , CCC, Tier 2
Front bezel colour	Black
Colour name	Raven Black
Product colour	Black

Ports & interfaces
Audio input	No
HDMI	No
DVI port	No
USB Power Delivery up to	65 W
USB Type-C DisplayPort Alternate Mode	Yes
Number of USB Type-C upstream ports quantity	2
Number of upstream ports	2
USB upstream port type	USB Type-C
Built-in USB hub	Yes

Ergonomics
Tilt adjustment	Yes
Number of OSD languages	8
On Screen Display (OSD)	Yes
Tilt angle range	-5 - 90°
Pivot angle	-90 - 90°
Pivot	Yes
Height adjustment	1.1 cm
Height adjustment	Yes
Cable lock slot type	Kensington
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
VESA mounting	Yes

Power
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (max)	9.5 W
Power consumption (typical)	8 W
Energy consumption (SDR) per 1000 hours	7 kWh
Energy efficiency class (SDR)	C

Operational conditions
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	10 - 80%
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C

Packaging content
Quick start guide	Yes
Cables included	USB Type-C to USB Type-C

Weight & dimensions
Bezel width (bottom)	3.04 cm
Bezel width (top)	5.42 mm
Bezel width (side)	5.43 mm
Weight (with stand)	698 g
Height (with stand)	226.5 mm
Depth (with stand)	14 mm
Width (with stand)	323.4 mm

Packaging data
Package weight	1.87 kg
Package height	68 mm
Package depth	377 mm
Package width	267 mm

Sustainability
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Logistics data
Harmonized System (HS) code	85285210

Other features
Multi-touch	Yes
