Intel Core Ultra 7 155H (24MB Cache), 16GB LPDDR5x-SDRAM, 1000GB SSD, 35.6 cm (14") Full HD+ 1920 x 1200 WVA, Intel Arc Graphics, NVIDIA RTX 1000 Ada (6GB GDDR6), WLAN, Webcam, Windows 11 Pro 64-bit

Intelligent performance. Outstanding user experience.
The world's smallest and most powerful 14" mobile workstation

Intelligent performance
Processor
Featuring the unique combined AI-engine of CPU, integrated Intel® Arc graphics GPU, and dedicated low-power AI engine NPU with Intel® AI Boost, and Intel vPro® options.

Graphics
Up to NVIDIA RTX™ 3000 Ada graphics, plus faster integrated Intel Arc graphics.

Scalable memory
Up to 64GB of 7467 MT/s, LPDDR5x dual channel memory.

Storage capabilities
1x M.2 2280 slot with PCIe Gen 4x4 support (up to 4TB).

Battery
Long battery life with 72 Whr long Life cycle option.

Connectivity
Flexible connectivity with WiFi 7 options.

Outstanding user experience
Experience
The 5490 is set with a large trackpad, dual array mics, four premium speakers, and optional Touch screen with Active Pen support.

Capture
HD IR camera complete with ambient light sensor and Windows Hello.

View
Expansive and stunning the 5490 has a 16:10 display with up to QHD+, 100% sRGB, 500nits brightness, and PremierColor. Complete with ComfortView Plus options to reduce blue light emissions.

Power to create your masterpieces
Built for work and design with creative applications like:Design - 2D, 3D CAD, Content creation Production, Photo, video and audio editing, Web Design, Graphic Design

AI at your fingertips
Next-level computing
Intel® Core™ Ultra processors enable AI-powered efficiency with AI accelerators within the world’s most intelligent commercial PCs featuring Intel® AI Boost, with vPro options and Copilot in Windows 11. Enjoy power-efficient performance for business workloads with this new CPU, GPU, and NPU three tier multi-processing architecture.

Time saver
Effortlessly jumpstart your workflow with the Copilot Hardware Key on your device, saving you time by providing quick access to the tools you need to start your workday.

AI-accelerated apps
Apps using AI run fast and smooth thanks to the dedicated NPU, so you can enjoy efficient Collaboration: Use up to 38% less power when using AI-enhanced collaboration tools during Zoom calls

Creativity
132% faster performance when running on-device AI photo editing on Adobe.

Security
Detect malware with less than 1% CPU utilisation using CrowdStrike.

Intelligent collaboration
Users enjoy smoother collaboration with AI-boosts that make Windows Studio Effects even better, with features like smart framing and noise suppression that don’t impact overall system performance.

Personalised performance
Dell Optimizer automatically responds to your workstyle with advance privacy features and built-in AI that optimises audio connectivity, productivity and configurability, all in one software.

Independent Software Vendor (ISV) certification
Precision workstations are tested to ensure the high-performance applications you rely on every day run smoothly.

Security
Windows Hello Compatible IR camera recognises you, increasing privacy and productivity.Fingerprint reader Uses biometrics to log you in to Dell Safeguard and response.Detect and prevent cyber attacks Dell Safe Data Prevent data breaches.SecureWorks responds to security incidents with Safe-mute. Dell Peripheral manager intelligent mic muting and video disabling.

VR and AI Compatibility
VR and AI capabilities allow you to experience fully-immersive content. Powerful enough for gaming, education, entertainment, and exploring the digital world. Precision 5490 has next generation professional graphics and powerful performance normally found only in tower workstations.

Advancing sustainability
Designed with sustainable materials
This Precision workstation incorporates up to 35% post-consumer recycled plastic content in various components including the LCD bezel, cable covers and keyboard frame .

Elevated Standards
Meeting environmental standards demonstrates how our products adhere to energy-efficiency and other extensive climate-related standards. This workstation is certified ENERGY STAR ® 8.0, TCO certified Generation 9, and EPEAT Gold registered with Climate+ .

Innovative packaging
This workstation ships in packaging made with 100% recycled or renewable materials that is also 100% recyclable.

Dell APEX PC-as-a-Service
Accelerate anywhere work experiences with customisable plans to help you deploy, manage, support devices. Leverage both the built-in protections of our secure commercial PCs and software protections for advanced threats to help ensure a trusted workplace for a predictable price per month.

Design
Intel® vPro™ Platform Eligibility	Yes
Market positioning	Business
Form factor	Clamshell
Product colour	Grey
Product type	Mobile workstation

Display
Contrast ratio (typical)	1000:1
Maximum refresh rate	60 Hz
RGB colour space	sRGB
Colour gamut	100%
Pixel density	161 ppi
Display brightness	500 cd/m²
Anti-glare screen	Yes
LED backlight	Yes
Native aspect ratio	16:10
Panel type	WVA
HD type	Full HD+
Touchscreen	No
Display resolution	1920 x 1200 pixels
Display diagonal	35.6 cm (14")

Processor
Processor base power	28 W
Maximum turbo power	115 W
Processor cache type	Smart Cache
Processor cache	24 MB
Processor cores	16
Performance cores	6
Efficient cores	8
Processor threads	22
Performance-core Max Turbo Frequency	4.8 GHz
Efficient-core Max Turbo Frequency	3.8 GHz
Processor boost frequency	4.8 GHz
Performance-core base frequency	1.4 GHz
Efficient-core base frequency	0.9 GHz
Processor model	155H
Low Power Efficient-core Base Frequency	700 MHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-cores	2
Processor generation	Intel® Core™ Ultra (Series 1)
Processor family	Intel Core Ultra 7
Processor manufacturer	Intel

Neural processor unit (NPU)
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, Windows ML
AI datatype support on NPU	FP16, FP32, Int8
Windows Studio effects support	Yes
Sparsity support	Yes
Maximum frequency NPU	1.4 GHz
Neural processor unit (NPU)	Intel AI Boost

Memory
Memory channels	Dual-channel
Memory data transfer rate	7467 MT/s
Maximum internal memory	16 GB
Memory form factor	On-board
Internal memory type	LPDDR5x-SDRAM
Internal memory	16 GB

Storage
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Card reader integrated	Yes
Optical drive type	No
SSD form factor	M.2
SSD performance class	40
M.2 SSD size	2280 (22 x 80 mm)
SSD interface	PCI Express 4.0
NVMe	Yes
SSD capacity	1 TB
Number of SSDs installed	1
Total SSDs capacity	1 TB
Storage media	SSD
Total storage capacity	1 TB

Graphics
Discrete graphics memory type	GDDR6
Discrete graphics card memory	6 GB
On-board graphics card model	Intel Arc Graphics
On-board graphics card family	Intel Arc Graphics
On-board GPU manufacturer	Intel
Discrete graphics card model	NVIDIA RTX 1000 Ada
Discrete graphics card	Yes
On-board graphics card	Yes

Audio
Number of microphones	2
Built-in microphone	Yes
Speaker power	2 W
Number of built-in speakers	4

Camera
Infrared (IR) camera	Yes
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Front camera HD type	HD
Front camera resolution (numeric)	0.92 MP
Front camera	Yes

Network
Bluetooth	Yes
WLAN controller model	Intel Wi-Fi 7 BE200
WLAN controller manufacturer	Intel
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Mobile network connection	No

Ports & interfaces
USB Power Delivery	Yes
USB Type-C DisplayPort Alternate Mode	Yes
Charging port type	USB Type-C
Combo headphone/mic port	Yes
Thunderbolt 4 ports quantity	4
Intel® Thunderbolt 4	Yes

Performance
Accelerometer	Yes
Hall sensor	Yes
Ambient light sensor	Yes

Keyboard
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	UK English
Pointing device	Touchpad

Software
Trial software	No Microsoft Office Licence Included - 30 day Trial Offer Only
Operating system language	German, Dutch, English, French, Italian
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro

Battery
Battery weight	285 g
Fast charging	Yes
Battery recharge time	4 h
Battery voltage	15.4 V
Battery capacity	72 Wh
Number of battery cells	4

Power
AC adapter input voltage	100 - 240 V
AC adapter frequency	50 - 60 Hz
AC adapter power	130 W

Security
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Fingerprint reader	Yes
Cable lock slot type	Wedge
Cable lock slot	Yes

Operational conditions
Non-operating vibration	1.3 G
Operating vibration	0.66 G
Non-operating shock	160 G
Operating shock	110 G
Non-operating altitude	-15.2 - 10668 m
Operating altitude	-15.2 - 3048 m
Storage relative humidity (H-H)	0 - 95%
Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C

Sustainability
Sustainability certificates	ENERGY STAR, TCO
Sustainability compliance	Yes

Weight & dimensions
Height (rear)	1.9 cm
Height (front)	7.49 mm
Depth	210.3 mm
Width	310.6 mm
Weight	1.49 kg

General
Product Family	Precision
Product Series	5000

Carbon footprint
Total carbon footprint	115
Carbon emissions (Manufacturing)	87
Carbon emissions (Logistics)	6
Carbon emissions (Use)	20
Carbon emissions (End-of-Life)	2
Total carbon emissions (w/o Use phase)	95
PAIA version	GaBi verison1

Packaging content
Cables included	AC
