ITX/Micro ATX/ATX/E-ATX, 33.44L, 4 x 3.5", 3 x 2.5", 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C, 1 x 3.5mm, 1x 120mm 1800RPM, White
CREATE IT YOUR WAY
Flatpack Assembly
Besides the clear eco-benefits, we believe flat-packing will provide a fun and satisfying build experience. Welcome to the future of PC DIY.
Fully Modular
Features modular panels that simplify and streamline the usual case prep process. Every panel is separately removable for easy maintenance.
Highly Customizable
An unprecedented level of customizability allows for full creative expression.
Full-sized SPECS, Pint-sized Body
The Qube 500 can house almost anything you would expect from a larger case, from EATX Motherboards and the latest GPUs to dual 280mm radiators.
Build As You Unbox
From the moment you open the box, the build begins with fun and easy step-by-step instructions.
Hardware Compatibilty
The Qube 500 is compatible with 280mm water coolers, 172mm air coolers, 173mm ATX PSUs, E-ATX motherboards and smaller, and 360mm GPUs.
Side Radiator Bracket
The side radiator mount has two positions, allowing you to install a 280mm radiator or provide your GPU with extra airflow.
Built-in Vertical GPU Bracket
Vertically mount your GPU with the included bracket. You can even adjust the distance from the side panel to maintain good airflow.
Accessory Ecosystem
The Qube 500 comes with a living accessory ecosystem. A Gem mini cable manager and a handle-bar is included, and we have prepared some 3D-printable files for you to create your own accessories.
| Design |
|---|
| Maximum PSU length |
33.2 cm |
| Maximum graphics card length |
36.5 cm |
| Maximum CPU cooler height |
17.2 cm |
| Cable management |
Yes |
| Anti-dust filter |
Yes |
| Side window |
Yes |
| Number of expansion slots |
7 |
| Number of 2.5" bays |
3 |
| Number of 3.5" bays |
4 |
| Supported motherboard form factors |
ATX, EATX, ITX, micro ATX |
| Product colour |
White |
| Material |
Plastic, Steel, Tempered glass |
| Type |
PC |
| Form factor |
Midi Tower |
| Power supply |
|---|
| Supported power supply form factors |
ATX, SFX, SFX-L |
| Power supply included |
No |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Cooling |
|---|
| Top radiator sizes supported |
120,140,240,280 mm |
| Rear radiator sizes supported |
120 mm |
| Bottom radiator sizes supported |
120,140,240,280 mm |
| Side radiator sizes supported |
120,140,240,280 mm |
| Front radiator sizes supported |
120,140 mm |
| Fan speed |
0 - 1800 RPM |
| Bottom fans diameters supported |
120,140 mm |
| Number of bottom fans supported (max) |
2 |
| Top fans diameters supported |
120,140 mm |
| Number of top fans supported (max) |
2 |
| Rear fans diameters supported |
120 mm |
| Number of rear fans supported (max) |
1 |
| Rear fans installed |
1x 120 mm |
| Side fans diameters supported |
120,140 mm |
| Number of side fans supported (max) |
2 |
| Front fans diameters supported |
120,140 mm |
| Number of front fans supported (max) |
1 |
| Storage |
|---|
| Supported HDD sizes |
2.5,3.5" |
| Weight & dimensions |
|---|
| Weight |
7.8 kg |
| Height |
415 mm |
| Depth |
406 mm |
| Width |
231 mm |
| Packaging data |
|---|
| Package weight |
9.42 kg |
| Package height |
146 mm |
| Package depth |
513 mm |
| Package width |
453 mm |
| Other features |
|---|
| Volume |
33.44 L |
