Chieftec CW-01B-OP Tower in Black
The CW-01B-OP is Chieftec’s interpretation of a high-performance workstation case, providing high functional flexibility with external and internal drives and diverse cooling options. Preinstalled dust filters guarantee you a dust-free system. Featuring a modern, yet timeless, design combining brushed aluminum and filtered mesh, the Chieftec CW-01B-OP provides great airflow for optimal workstation performance.
| Design | |
|---|---|
| Maximum graphics card length | 41 cm |
| Maximum CPU cooler height | 16.5 cm |
| Anti-dust filter | Yes |
| Illumination | No |
| Side window | No |
| Number of expansion slots | 7 |
| Number of external 5.25" bays | 3 |
| Number of internal 3.5" bays | 7 |
| Number of 2.5" bays | 7 |
| Number of 3.5" bays | 7 |
| Number of 5.25" bays | 3 |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Product colour | Black |
| Material | SPCC |
| Type | PC |
| Form factor | Tower |
| Power supply | |
|---|---|
| Supported power supply form factors | ATX |
| Power supply location | Bottom |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| Audio output | Yes |
| Audio input | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Cooling | |
|---|---|
| Top radiator sizes supported | 280 mm |
| Bottom fans diameters supported | 120,140 mm |
| Number of bottom fans supported (max) | 1 |
| Top fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 2 |
| Side fans diameters supported | 120 mm |
| Number of side fans supported (max) | 1 |
| Front fans diameters supported | 120 mm |
| Number of front fans supported (max) | 2 |
| Storage | |
|---|---|
| HDD/SSD combo cage | Yes |
| Supported HDD sizes | 2.5,3.5" |
| Weight & dimensions | |
|---|---|
| Material thickness | 0.7 mm |
| Weight | 6.8 kg |
| Height | 471 mm |
| Depth | 490 mm |
| Width | 210 mm |
| Packaging data | |
|---|---|
| Package weight | 7.8 kg |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733080 |
