Chieftec CS-12B-300 Mini Tower in Black
The mATX all-rounder – Compact and multifunctional mATX chassis... whether horizontally or vertically positioned, the CS-12B-300 remains an eyecatcher. All components are easily installed thanks to the quick-release bracket technology. With 4 expansion slots, up to 4x Half-Height PCI cards can be installed. The CS-12B-300 comes bundled with the powerful low-noise TFX power supply GPF-300P.
| Design | |
|---|---|
| Maximum graphics card length | 19.5 cm |
| Maximum CPU cooler height | 8.5 cm |
| On/off button | Yes |
| Reset button | Yes |
| Illumination | No |
| Suitable for | Home/Office |
| Side window | No |
| Number of expansion slots | 4 |
| Half-Height expansion slots | 4 |
| Number of external 5.25" bays | 1 |
| Number of 2.5" bays | 1 |
| Number of 3.5" bays | 1 |
| Number of 5.25" bays | 1 |
| Supported motherboard form factors | Mini-ITX |
| Product colour | Black |
| Material | SGCC |
| Type | PC |
| Form factor | Mini Tower |
| Power supply | |
|---|---|
| Power supply | 300 W |
| Power supply included | Yes |
| Ports & interfaces | |
|---|---|
| Audio output | Yes |
| Audio input | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| Cooling | |
|---|---|
| Front fans diameters supported | 80 mm |
| Number of front fans supported (max) | 1 |
| Front fans installed | 1x 80 mm |
| Storage | |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| Weight & dimensions | |
|---|---|
| Material thickness | 0.6 mm |
| Weight | 4.75 kg |
| Height | 338 mm |
| Depth | 356 mm |
| Width | 102 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733080 |
