Azza CUBE MINI 805 - Mini ITX Tower Case in Silver
The Cube Mini is the little brother of our bigger Cube 802 case. While sporting an identical cube appearance, the Cube Mini is designed for those with a more minimalist setup.
Supporting a maximum of mini-ITX motherboards and video cards up to 200mm long, the Cube Mini boasts compactness.
The Cube Mini sports 2 tempered glass side panels, which helps display your rig.
The front of the case can support a single 120mm or 140mm fan, while the back can hold a 80mm fan for enhanced air circulation.
In terms of storage, the Cube Mini can hold up to two 2.5” drives, whether it’s an SSD or an HDD, which is plenty for a minimalist setup.
The case comes included with a 140mm digital RGB fan on the front, which can be controlled directly by motherboard software with any compatible motherboard.
The Cube Mini 805 is a great option for those who want the unique and innovative design of the Cube 802, but don’t need all the extra bells and whistles.
Hurricane II Digital RGB Fan Installation For Motherboard
Connecting a strip to an incorrect connector can potentially cause damage to the LED strip, due to the RGB, and Digital RGB connectors providing different voltages .
Our digital RGB devices are WS2812B-compliant. Each fan contains 18 digital/addressable LED diodes. The WS2812B standard supports up to 60 diodes at the maximum for a single header, so please do not daisy-chain more than 3 digital RGB fans together.
| Design | |
|---|---|
| Maximum graphics card length | 20 cm |
| Maximum CPU cooler height | 13 cm |
| On/off button | Yes |
| Tempered glass panel(s) | Yes |
| Illumination location | Front |
| Illumination colour | Multi |
| Illumination | Yes |
| Side window | Yes |
| Number of expansion slots | 3 |
| Number of 2.5" bays | 2 |
| Supported motherboard form factors | Mini-ATX |
| Product colour | Silver |
| Material | Aluminium, Tempered glass |
| Type | PC |
| Form factor | Cube |
| Power supply | |
|---|---|
| Power supply location | Bottom |
| Number of power supply units | 1 |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| Audio output | Yes |
| Audio input | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Cooling | |
|---|---|
| Front radiator sizes supported | 120,140 mm |
| Rear fans diameters supported | 80 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans installed | 1x 80 mm |
| Front fans diameters supported | 120,140 mm |
| Number of front fans supported (max) | 1 |
| Front fans installed | 1x 140 mm |
| Storage | |
|---|---|
| Supported HDD sizes | 2.5" |
| Weight & dimensions | |
|---|---|
| Weight | 5.4 kg |
| Height | 472 mm |
| Depth | 372 mm |
| Width | 371 mm |
- AZZA CUBE MINI 805
