ASUS TUF Gaming - NVIDIA 12 GB GDDR6X GeForce RTX 4070 graphics card
-
Powered by NVIDIA DLSS3, ultra-efficient Ada Lovelace arch, and full ray tracing.
-
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
-
3rd Generation RT Cores: Up to 2x ray tracing performance
-
OC mode: 2580 MHz (OC mode)/ 2550 MHz (Default mode)
-
Axial-tech fans scaled up for 21% more airflow
-
Dual ball fan bearings last up to twice as long as conventional designs
-
Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable
-
Vented exoskeleton adds structural rigidity and vents to increase heat reliability
-
Auto-Extreme precision automated manufacturing for higher reliability
-
GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring.
ARMED FOR FLOW
NVIDIA Ada Lovelace architecture elevated by buffed cooling and power delivery,
and backed with an arsenal of rugged reinforcements to cover your six.
Lock, load, and dominate with the TUF Gaming GeForce RTX™ 4070.
Powered by GeForce RTX 40 Series and DLSS 3
New Streaming Multiprocessors
Up to 2x performance and power efficiency
Fourth-Gen Tensor Cores
Up to 4x performance with DLSS 3
vs. brute-force rendering
Third-Gen RT Cores
Up to 2x ray tracing performanceAXIAL-TECH UPGRADES
Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 21% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
AXIAL-TECH UPGRADES
Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 21% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
NEW DIRECTION
Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
3.15-SLOT DESIGN
Phase That Blaze
A generously oversized heatsink combo efficiently soak up heat from the GeForce RTX 4070 GPU so that it can be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS
Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
VENTED EXOSKELETON
Stay Frosty
The backplate is made of sturdy aluminium to brace the PCB and sink heat away from onboard components.
AUTO-EXTREME TECHNOLOGY
Reliability Boost
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
AURA SYNC
Light ‘em Up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.
| Processor | |
|---|---|
| Parallel processing technology support | Not supported |
| Maximum displays per videocard | 4 |
| Processor frequency (OC mode) | 2580 MHz |
| Processor boost clock speed | 2550 MHz |
| CUDA cores | 5888 |
| CUDA | Yes |
| Maximum resolution | 7680 x 4320 pixels |
| Graphics processor | GeForce RTX 4070 |
| Graphics processor family | NVIDIA |
| Memory | |
|---|---|
| Data transfer rate | 21 Gbit/s |
| Memory bus | 192 bit |
| Graphics card memory type | GDDR6X |
| Discrete graphics card memory | 12 GB |
| Ports & interfaces | |
|---|---|
| DisplayPort version | 1.4a |
| HDMI version | 2.1 |
| DisplayPorts quantity | 3 |
| HDMI ports quantity | 1 |
| Interface type | PCI Express 4.0 |
| Performance | |
|---|---|
| AMD FreeSync | No |
| NVIDIA G-SYNC | Yes |
| HDCP | Yes |
| HDCP version | 2.3 |
| OpenGL version | 4.6 |
| DirectX version | 12 Ultimate |
| Design | |
|---|---|
| Product colour | Grey |
| Illumination | Yes |
| Illumination colour | Blue, Green, Red |
| Number of slots | 3.15 |
| Form factor | Full-Height/Half-Length (FH/HL) |
| Number of fans | 3 fan(s) |
| Cooling technology | ASUS Axial-tech |
| Cooling type | Active |
| Power | |
|---|---|
| Supplementary power connectors | 1x 8-pin |
| Minimum system power supply | 650 W |
| General | |
|---|---|
| Product Family | TUF Gaming |
| Weight & dimensions | |
|---|---|
| Depth | 139 mm |
| Height | 63 mm |
| Width | 301 mm |
| Weight | 968 g |
| Packaging data | |
|---|---|
| Package type | Box |
| Package weight | 1.73 kg |
| Package height | 87 mm |
| Package depth | 226 mm |
| Package width | 420 mm |
