NVIDIA GeForce RTX 4090 24GB GDDR6X, OpenGL®4.6, 384-bit, 7680 x 4320, 348.2 x 160 x 72.6 mm

ASUS TUF Gaming GeForce RTX® 4090 24GB GDDR6X optimized inside and out for lower temps and durability.

Armed for Flow
The NVIDIA Ada Lovelace architecture elevated by buffed cooling and power delivery, and backed with an arsenal of rugged reinforcements to cover your six. Lock, load, and dominate with the TUF Gaming GeForce RTX® 4090.

Axial-tech Upgrades
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 23% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.

Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 Celsius, referencing a speed curve that balances performance and acoustics for work or play.

Phase That Blaze
A vapor chamber and generously sized heatsink combo efficiently soak up heat from the GeForce RTX 4090 GPU so that it can be whisked away by the three Axial-tech fans.

Military-grade 20K Capacitors
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.

Metal Exoskeleton
A high-quality diecast shroud and aluminum backplate prevent PCB flex and feature large vents to further increase heat dissipation.

Auto-Extreme Technology
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.

Light ‘em Up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.

Processor
Parallel processing technology support	Not supported
Maximum displays per videocard	4
Processor frequency (OC mode)	2550 MHz
Processor boost clock speed	2520 MHz
CUDA cores	16384
CUDA	Yes
Maximum resolution	7680 x 4320 pixels
Graphics processor	GeForce RTX 4090
Graphics processor family	NVIDIA

Memory
Data transfer rate	21 Gbit/s
Memory bus	384 bit
Graphics card memory type	GDDR6X
Discrete graphics card memory	24 GB

Ports & interfaces
DisplayPort version	1.4a
HDMI version	2.1a
DisplayPorts quantity	3
HDMI ports quantity	2
Interface type	PCI Express 4.0

Performance
AMD FreeSync	No
NVIDIA G-SYNC	Yes
Dual Link DVI	No
HDCP	Yes
HDCP version	2.3
OpenGL version	4.6
TV tuner integrated	No

Design
Product colour	Black
Illumination	Yes
Illumination colour	Blue, Green, Red
Number of slots	3.65
Form factor	Full-Height/Full-Length (FH/FL)
Number of fans	3 fan(s)
Cooling type	Active

Power
Supplementary power connectors	1x 16-pin
Minimum system power supply	850 W

General
Product Family	TUF Gaming

Weight & dimensions
Depth	72.6 mm
Height	160 mm
Length	348.2 mm

Packaging data
Package type	Box
Manual	Yes
