ARCTIC P8 PWM PST CO - Pressure-optimised Computer Case Fan - 80mm
Optimised for Static Pressure
During the development of the new P8 PWM PST CO, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P8 PWM PST CO is particularly suitable for use on heatsinks and radiators.
For Continuous Operation
The premium quality Japanese dual ball bearing allows continuous operation 24/7 without the slightest compromise in performance. Dust and high temperature are affecting this bearing a lot less than generic sleeve or one ball bearings and thus make it the perfect choice when reliability is essential.
Maximum Quietness, Minimum Vibration
Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable.Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.
Extended Life Span
A 10 °C lower motor temperature roughly doubles the life span of a fan.The new ARCTIC motor has a four times longer service life through its low coil temperature.Consequently, we have extended the warranty to 10 years.
200 to 3000 RPM regulated via PWM
With a wide range of regulation and the PWM Sharing Technology (PST), the P8 PWM PST CO fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed.
Two Way Installation
Push warm air out of the case or pull cool air into your case
| Performance | |
|---|---|
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Pulse-width modulation (PWM) support | Yes |
| Maximum air pressure | 1.9 mmH2O |
| Airflow | 40.3 m³/h |
| Maximum airflow | 23.4 cfm |
| Noise level | 0.3 sone |
| Rotational speed (max) | 3000 RPM |
| Rotational speed (min) | 200 RPM |
| Compatible processor series | Not supported |
| Supported processor sockets | Not supported |
| Fan diameter | 8 cm |
| Type | Fan |
| Suitable location | Computer case |
| Design | |
|---|---|
| Fan connector | 4-pin |
| Number of fan blades | 5 |
| Number of fans | 1 fan(s) |
| Product colour | Black |
| Power | |
|---|---|
| Rated current | 0.09 A |
| Voltage | 12 V |
| Weight & dimensions | |
|---|---|
| Package weight | 97 g |
| Package height | 82.5 mm |
| Package depth | 26 mm |
| Package width | 82.5 mm |
| Weight | 78.5 g |
| Height | 80 mm |
| Depth | 25 mm |
| Width | 80 mm |
| Packaging content | |
|---|---|
| Manual | Yes |
| Number of screws | 4 |
| Screws included | Yes |
| Package type | Box |
| Other features | |
|---|---|
| Country of origin | China |
| Mounting hole pattern (W x D) | 71.5 x 71.5 mm |
